EVT-IM04GP+2UL-M12 INDUSTRIAL 04-PORT Gigabit PoE+ 2-PORT
10/100/1000T MANAGED ETHERNET SWITCH |
|
|
|
|
|
|
|
| Hardware Specifications |
| Copper Ports |
|
4 10/100/1000BASE-T waterproof and dustproof RJ45 auto-MDI/MDI-X ports |
|
PoE Injector Port |
|
4 ports with 802.3at/af PoE injector function |
| Switch Architecture |
|
Store-and-Forward |
|
Switch Fabric |
|
12Gbps/non-blocking |
| Throughput |
|
8.9Mpps@64bytes |
|
Address Table |
|
8K entries, automatic source address learning and aging |
| Shared Data Buffer |
|
4Mbits |
|
Flow Control |
|
- IEEE 802.3x pause frame for full-duplex
- Back pressure for half-duplex
|
| Connections |
|
- PoE ports
- RJ45 10Base-T/100Base-TX/1000Base-T Mbps (4x)
- Uplink
- SFP port (1x)
- Power
- Power connector port
|
|
Dimensions (W x D x H) |
|
105 x 70 x 171 mm |
| Weight |
|
1.3kg |
|
Surge Protection |
|
6KV DC |
| PoE Standard |
|
IEEE 802.3af/802.3at PoE/PSE |
|
PoE Ability |
|
- PD @ 61.4 watts: 2 units
- PD @ 30.8 watts: 2 units
- Budget @ 152 watts max
|
|
|
|
|
|
|
|
| Layer 2 Functions |
| Port Configuration |
|
- Port disable/enable
- Auto-negotiation 10/100/1000Mbps full and half duplex mode selection
- Flow control disable/enable
|
|
VLAN |
|
- 802.1Q tagged based VLAN
- Q-in-Q tunneling
- Private VLAN Edge (PVE)
- MAC-based VLAN
- Protocol-based VLAN
- Voice VLAN
- IP Subnet-based VLAN
- MVR (Multicast VLAN registration)
- Up to 255 VLAN groups, out of 4095 VLAN IDs
|
| Link Aggregation |
|
- IEEE 802.3ad LACP/static trunk
- 3 groups with 2 port per trunk
|
|
Spanning Tree Protocol |
|
- IEEE 802.1D Spanning Tree Protocol (STP)
- IEEE 802.1w Rapid Spanning Tree Protocol (RSTP) IEEE 802.1s Multiple Spanning Tree Protocol (MSTP)
|
| IGMP Snooping |
|
- IGMP (v2/v3) snooping IGMP querier
- Up to 256 multicast groups
|
|
MLD Snooping |
|
IPv6 MLD (v1/v2) snooping, up to 255 multicast groups, IGMP querier mode support |
| QoS |
|
- 8-level priority switching
- Port number
- 802.1p priority
- 802.1Q VLAN tag
- DSCP/ToS field in IP packet
|
|
Port Mirroring |
|
- TX/RX/Both
- Many-to-1 monitor
|
|
|
|
|
|
|
|
| Layer3 Functions |
| IP Interfaces |
|
Max. 6 VLAN interfaces |
|
Routing Table |
|
Max. 32 routing entries |
| Routing Protocols |
|
- IPv4 software static routing
- IPv6 software static routin
|
|
|
|
|
|
|
|
| Management Functions |
| Basic Management Interfaces |
|
Telnet/Web browser/SNMP v1, v2c |
|
Secure Management Interfaces |
|
SSH, SSL, SNMPv3 |
| System Management |
|
- Firmware upgrade by HTTP/TFTP protocol through Ethernet network LLDP protocol
- SNTP
- PLANET Smart Discovery Utility PLANET NMS System
|
|
SNMP MIBs |
|
- RFC 1213 MIB-II
- RFC 1493 Bridge MIB
- RFC 1643 Ethernet MIB
- RFC 2863 Interface MIB
- RFC 2665 Ether-Like MIB
- RFC 2819 RMON MIB (Group 1, 2, 3 and 9)
- RFC 2737 Entity MIB
- RFC 2618 RADIUS Client MIB
- RFC 2863 IF-MIB
- RFC 2933 IGMP-STD-MIB
- RFC 3411 SNMP-Frameworks-MIB
- RFC 4292 IP Forward MIB
- RFC 4293 IP MIB
- RFC 4836 MAU-MIB
- IEEE 802.1X PAE
- LLDP
- Power over Ethernet MIB
|
|
|
|
|
|
|
|
| Standards Conformance |
| Regulatory Compliance |
|
FCC Part 15 Class A, CE |
|
Standards Compliance |
|
- IEEE 802.3 10BASE-T
- IEEE 802.3u 100BASE-TX/100BASE-FX
- IEEE 802.3z Gigabit SX/LX IEEE 802.3ab Gigabit 1000T
- IEEE 802.3x flow control and back pressure
- IEEE 802.3ad port trunk with LACP IEEE 802.1D Spanning Tree Protocol
- IEEE 802.1w Rapid Spanning Tree Protocol IEEE 802.1s Multiple Spanning Tree Protocol IEEE 802.1p Class of Service
- IEEE 802.1Q VLAN tagging
- IEEE 802.1x Port Authentication Network Control IEEE 802.1ab LLDP
- IEEE 802.3af Power over Ethernet IEEE 802.3at Power over Ethernet Plus
- IEEE 802.3az Energy Efficient Ethernet (EEE)
- RFC 768 UDP
- RFC 793 TFTP
- RFC 791 IP
- RFC 792 ICMP
- RFC 2068 HTTP
- RFC 1112 IGMP version 1
- RFC 2236 IGMP version 2
- RFC 3376 IGMP version 3
- RFC 2710 MLD version 1
- RFC 3810 MLD version 2 ITU G.8032 ERPS Ring
|
|
|
|
|
|
|
|
| Environment |
| Operating |
|
- Temperature: -40 ~ 75 degrees C
- Relative Humidity: 5 ~ 95% (non-condensing)
|
|
Storage |
|
- Temperature: -40 ~ 80 degrees C
- Relative Humidity: 5 ~ 95% (non-condensing)
|
|
|
|
|
|
|
|
