Description
| Camera | |
| Image Sensor | 1/1.8ʺ Progressive Scan CMOS (EA) |
| Max. Resolution | 3840×2160 (EA) |
|
Min. Illumination |
Color: 0.006 Lux @ (F1.2, AGC ON), B/W: 0.002 Lux @ (F1.2, AGC ON);
0 Lux with IR on/White light on |
| Shutter Time | 1/5s – 1/20,000 s |
| Day & Night | IR Cut Filter |
|
Angle Adjustment |
Four flexible lens in one track, slide range: -60° to 60°, tilt: 0° to 90°, rotate: 0° to 355° |
| Lens | 2.8 ~ 12 mm，Varifocal motorized lens |
|
Focal Length & FOV |
Horizontal field of view: 48° to 112°,Vertical field of view: 27° to 58°, Diagonal field of view: 55° to 138° |
| Lens Mount | ø16.7 |
| Aperture | Max. F1.40 |
| Illuminator | |
| Supplement Light Type | IR |
| Supplement Light Range | Up to 30m |
| IR Wavelength | 850 nm |
| Smart Supplement Light | Yes |
| Video | |
| Main Stream | 50/60Hz: 25fps 8MP(3840×2160),5MP(2592×1944,3072×1728),
4MP(2592×1520),3MP(2304×1296),1080P(1920×1080), 960P(1280×960),720P(1280×720) |
| Sub-Stream | 50/60 Hz: 25fps 720P(1280×720),VGA(640×480),QVGA(320×240) |
| Mobile Stream | 50/60 Hz: 25fps 640×480, 320×240 |
|
Video Compression |
Main stream: H.265+/H.265/H.264+/H.264,
Sub stream: H.265+/H.265/H.264+/H.264/MJPEG, Mobile stream: H.265+/H.265/H.264+/H.264 |
| Video Bit Rate | 8Kbps to 16 Mbps |
| H.264 Type | Baseline Profile/Main Profile/High Profile |
| H.265 Type | Main Profile |
| Region Of Interest (ROI) | Yes |
| Audio | |
| Audio Compression | G.711 |
| Audio Bit Rate | Auto |
| Audio Sampling Rate | 8 kHz |
| Environment Noise Filtering | Yes |
| Network | |
|
Protocols |
TCP/IP,HTTP,DHCP,DNS,DDNS,RTP/RTSP, SMTP,NTP,UPnP,SNMP,HTTPS,FTP,PPPoE |
| Simultaneous Live View | Up to 92 streams |
| API | ONVIF( Profile S/G/T) |
| User/Host | Up to 32 users, 2 levels: Administrator and User |
|
Web Browser |
IE10/11
Safari V12.1 above Firefox V.52 above Google chrome V.57 above Edge V.79 above |
| Image | |
|
Image Settings |
Rotate mode, saturation, brightness, contrast, sharpness, and white balance are adjustable by client software or web browser |
| Day/Night Switch | Day/Night/Image/Schedule |
| Wide Dynamic Range (WDR) | 120 dB |
| Image Enhancement | BLC, 3D DNR, HLC |
| Interface | |
| Image Enhancement | 1 RJ45 10M/100M/1000M Ethernet port |
| On-Board Storage | Built-in Micro SD/SDHC/SDXC slot, up to 256GB |
| Audio | 1 input (RCA), 1 output (RCA) |
| Alarm | 2 inputs, 2 outputs |
| Reset | Yes |
| Event | |
| Basic Event | Motion detection |
|
Smart Event |
Face Recogniton, Pedestrian&Vehicle Detection, Line Crossing, Object Detection, CrossCounting, Heat Map, Crowd Density, Queue Length, License Plate Recognition, Intrusion,
Region Entrance, Region Exiting |
| General | |
| Power | Max. 33W |
| Input Voltage / Current | ACV24/DCV12/Hi-PoE |
| Material | Alloy |
| Dimension | Ø 300 mm × 195 mm (11.8″ x 7.7″) |
| Package Dimension | 500 mm × 395 mm × 385 mm (19.7″ x 15.6″ x 15.2″) |
| Weight | Camera：Approx. 4.6kg(10.1lb) |
| Operating Conditions | -30～+55°C/less than ≤ 95% RH |
| Protection | IP67, IK10 |
