| Processor |
Intel Xeon Silver 4210R 2.4GHz, 10C/20T, 13.75M Cache |
| Memory |
16GB (2x 8GB) 3200MT/s ECC DDR4 |
| Live Database Storage |
2x 480GB SATA Solid State Drives, RAID1 |
| Recording Storage |
144TB (12x 12TB) 7.2K RPM NLSAS SATA 3.5in Hard Disk Drives, 120TB RAID5 |
| System Storage |
2x 240GB Solid State Drives, RAID1 |
| RAID Support |
0, 1, 5, 6 & 10 |
| Preinstalled Licenses |
64 Preinstalled EVT VMS Camera Licenses up to 12MP/each |
| Operating System |
Windows Server 2019 Standard with Built-in Operating System Recovery Feature |
| Network |
4x 1Gbps Ethernet Ports |
| Remote Management |
iDRAC9, Enterprise |
| Video Output |
VGA |
| Power Supply |
Dual, Hot-Plug Redundant 750W |
| Input Voltage |
240vAC |
| USB |
Front: 1x USB 2.0 / Rear: 2x USB 3.0 |
| Form Factor |
2RU with ReadyRails Sliding Rails |
| Compliance/Approvals |
- NDAA (National Defense Authorization Act)
TAA (Trade Agreements Act)
- EMC
EN 55032 Class A, EN 55024, EN 55035,
EN 61000-3-2, EN 61000-3-3,
FCC Part 2 and 15 Class A,
ISED ICES-003 Class A,
RCM AS/NZS CISPR 32 Class A,
KS C 9832 Class A, KS C 9835,
VCCI 32-1 Class A, BSMI
- Safety
IEC/EN/UL 60950-1,
IEC/EN/UL 62368-1, EN 62311,
NOM-019-SCFI-1998
|
| Dimensions |
(H x W x D) 8.7cm x 43.4cm x 69.4cm |
| Weight |
29.7 kg |
| Operating Temperature |
Operating temperature range from 10° C to 35° C |
| Operating Humidity |
Operating relative humidity range from 10% to 80% |
| Warranty |
5-Years |
