Description
| Image sensor | Uncooled Micro bolometer 640×480, pixel size: 17 μm
Spectral range: 8-14 μm |
Sensitivity | NETD < 50 mK | |||
| Lens | Athermalized
10 mm Horizontal field of view: 63°, F1.24 Near focus distance: 2.8 m (9.2 ft) 19 mm Horizontal field of view: 31°, F1.23 Near focus distance: 9.2 m (30 ft) 35 mm Horizontal field of view: 17°, F1.20 Near focus distance: 33 m (108 ft) 60 mm Horizontal field of view: 10°, F1.25 Near focus distance: 91 m (300 ft) |
Pan/Tilt | Preset positions, guard tour, driver selection, control queue | |||
| Network | ||||||
| Security | Password protection, IP address filtering, HTTPSa encryption, IEEE 802.1x (EAP-TLS)a network access control, digest authentication, user access log, centralized certificate management, brute force delay protection, signed firmware | Supported protocols | IPv4, IPv6 USGv6, HTTP, HTTPSa, SSL/TLSa, QoS Layer 3 DiffServ, FTP, CIFS/SMB, SMTP, Bonjour, UPnPTM, SNMP v1/v2c/v3 (MIB-II), DNS, DynDNS, NTP, RTSP, RTP, SRTP, SFTP, TCP, UDP, IGMPv1/v2/v3, RTCP, ICMP, DHCP, ARP, SOCKS, SSH, LLDP, MQTT v3.1.1 | |||
| VIDEO | ||||||
| compression | H.264 (MPEG-4 Part 10/AVC) Baseline, Main and High Profiles
Motion JPEG |
Resolution | Sensor is 640×480. Image can be scaled up to 800×600 (SVGA) | |||
| Frame rate | Up to 8.3 fps and 30 fps | Video streaming | At least three H.264 and Motion JPEG streams, simultaneous and individually configured in max. resolution in full frame rate | |||
| Image settings | Compression, brightness, sharpness, contrast, exposure zone, text and image overlay, privacy mask, mirroring of images, electronic image stabilization, multiple palettes Rotation: 0°, 180° | |||||
| SYSTEM INTEGRATION | ||||||
| Application Programming Interface | Open API for software integration, including VAPIX® andEVT Camera Application Platform; specifications at eaglevisiontech.com
EVT Video Hosting System (AVHS) with One-Click Connection One-click cloud connection ONVIF® Profile G and ONVIF® Profile S specification at onvif.org |
|||||
| ANALYTICS | ||||||
| Applications |
Motion Guard, Fence Guard, Loitering Guard Video Motion Detection, shock detection
Perimeter Defender Support for Camera Application Platform enabling installation of third-party applications |
|||||
| GENERAL | ||||||
| Casing | IP66- and NEMA 4X-rated
Metal casing (aluminum) with integrated dehumidifying membrane and a germanium window Color: White NCS S 1002-B |
Memory | 512 MB RAM, 256 MB Flash | |||
| Power | Power over Ethernet IEEE 802.3af/802.3at Type 1 Class 3
Typical 4.8 W, max 11.8 W 8–28 V DC, typical 6.6 W, max 13 W 20–24 V AC (50/60 Hz), typical 11 VA, max 19 VA Power supply not included. |
Connectors | RJ45 10BASE-T/100BASE-TX PoE
Terminal block for power RS485/RS422 for pan/tilt control |
|||
| Storage | Support for microSD/microSDHC/microSDXC card
Support for SD card encryption Support for recording to network-attached storage (NAS) |
Operating conditions | -40 °C to 60 °C (-40 °F to 140 °F)
Humidity 10–100% RH (condensing) De-icing capability, compliant to MIL-STD-810F Method 521.3 |
|||
| Storage |
|
Operating conditions |
|
|||
| Storage conditions | -40 °C to 70 °C (-40 °F to 158 °F) | Included accessories | Torx® T20 screw driver, Terminal block connector
Installation Guide, Windows® decoder 1-user license |
|||
| Dimensions | 309 x 105 mm (12 3/16 x 4 1/8 in) | Weight | 10/19 mm: 1800 g (4.0 lb)
Mount 35 mm: 1900 g (4.2 lb) Mount 60 mm: 2000 g (4.4 lb) |
|||
| Approvals |
EN 55022 Class A, EN 50121-4, IEC 62236-4, EN 55024, EN 61000-6-1, EN 61000-6-2, FCC Part 15 Subpart B Class A, ICES-003 Class A, VCCI Class A, RCM AS/NZS CISPR22 Class A KCC KN32 Class A, KN35
EN 62368-1
EN 50581, NEMA 250 Type 4X, IEC 60068-2-1, IEC 60068-2-2, IEC 60068-2-6 Class 4M4, IEC 60068-2-27, IEC 60068-2-52, IEC 60721-3-4 Class 4K3, MIL-STD-810F Method 521.3 IEC 60529 IP66
NIST SP500-267 |
|||||
