Description
| Image Sensor | 1/2.8″ SONY Starvis Back-illuminated CMOS | Tri Stream | 1280*720@25fps, 720*480@25fps, 352*288@25fps | |
| Resolution | 8MP | IE Brower | IE8-11, Google Chrome, Firefox, Mac Safari | |
| Effective Pixels | 3864(H)*2192(V) | Smart Phone | iPhone, Android | |
| Compression | H.264/H.264+/H.265/H.265+/JPEG/AVI /MJPEG | AI Function | ||
| Audio Compression | G711A/U, AAC | Intelligent Analysis | Intrusion Detetion(based on human and Vehicle Detection), Line Cross Detetion(based on human and Vehicle Detection), Loiter Detetion, People Gather Detecion(based on human detection),Motion detection based on human detection,Upload face capture to FTP | |
| TV System | PAL/NTSC | |||
| Electronic Shutter Time | Auto: 1/3-1/100000Sec | |||
| Minimum Illumination | Color: 0.01 Lux @ (F1.6, AGC ON), B/W: 0 Lux with IR | Camera Features | ||
| S/N Ratio | 60dB | Day/Night | Color/ B&W (IR-CUT) | |
| Scanning System | Progressive | Image Config | Saturation/Brightness/Contrast /Sharpness, Mirror, 3D NR, White Balance, Anti Flicker, Video Tampering, HLC, Distortion | |
| Video Output | Network | |||
| Reset Button | Optional | Full Color | N/A | |
| Lens | Corridor Pattern | Support | ||
| Focal Length & FOV | 2.7-13.5mm Motor Zoom, horizontal FOV 103°—29°, vertical FOV 54°—16°, diagonal FOV 124°—33° | Defog Mode | Support | |
| Lens Type | Auto | ROI | Support | |
| Focus Control | Auto | BLC | Support | |
| Aperture | F1.6 – F3.3 | WDR | 140dB | |
| Pixels | 8MP | Motion Detection | Support (support enable the detection based on human movement only) | |
| Night Vision | Privacy Masking | 3 Rectangular Zone | ||
| Infrared LED | 42µ x 4PCS | Recording Mode | NVR/CMS/Web | |
| Infrared Distance | 40m | Language | Chinese Simplified, Chinese Traditional, English, Bulgarian, Polish, Arabic, German, Russian, French, Korean, Portuguese, Japanese, Turkish, Spanish, Hebrew, Italian, Nederland, Czech, Vietnamese | |
| IR Status | Auto Control | |||
| IR Power On | Smart, Manual & Timed mode | Interface | ||
| Network | Audio | Optional Audio IN/OUT | ||
| Ethernet | RJ-45 (10/100Base-T) | Alarm | Optional 1 Channel Input/output | |
| Wireless | N/A | SD Card Slot | Optional External, Support Max 1TB, Built in 4G Storage | |
| Protocol | TCP/IP, IPv4/v6, ICMP, HTTP, HTTPS, FTP, DHCP, DNS, DDNS, RTP, RTSP, RTCP, PPPoE, NTP, SMTP, UDP, SNMP, Qos,802.1x | RS485 | N/A | |
| ONVIF | Support ONVIF 19.12(Profile S/T/G) | General | ||
| P2P | YES | Housing | Metal, IP67, IK10 | |
| POE | Internal, Support IEEE 802.3af | Anti-cut Bracket | No | |
| Video Delay | 0.3S (Within the Lan) | IR Cut Filter | YES | |
| Main Stream 1 | 3840*2160@25fps, 3072*2048@25fps | Operation Temperature | -20℃ ~ +60℃ RH95% Max | |
| Main Stream 2 | 2592*1536@25fps, 2560*1440@25fps | Storage Temperature | -20℃ ~ +60℃ RH95% Max | |
| Main Stream 3 | 1920*1080@25fps, 1280*720@25fps | Power Source | DC12V±10%, 950mA | |
| Sub Stream 1 | 1280*720@25fps, 720*480@25fps | Dimension | 140(W) x 128(H) x 140(D)mm | |
| Sub Stream 2 | 352*288@25fps, | Weight | 1200g | |
Accessories
 |
Outdoor Long Wall-Mount Bracket
EVT-WM236-OL – Material: Metal – Color: White – Size (mm): 245 (W) x 160(D) x 163(H) |
 |
Ceiling-Mount Bracket
EVT-CM236 – Material: Plastic – Color: White – Size (mm): 116 (W) x 116(D) x 49.4(H) |
 |
Indoor Short Wall-Mount Bracket
EVT-WM236-IS – Material: Metal – Color: White – Size (mm): 173 (W) x 111 (D) x 114(H) |
 |
Junction Box
EVT-JB236 – Material: Plastic – Color: White – Size (mm): 138.5 (L) x 137.4(W) x 65.5(H) |
